TRAVEL DRIVES
Main winch / travel drive
Planetary gearbox for the main winch and crawler travel of rotary drilling rigs, ratio 115.
- Ratio
- 115
- Output torque
- —
Overview
Three-stage planetary reduction with a ratio of 115, used for main winch hoisting and crawler travel on rotary drilling rigs.
The housing has a flanged mounting face and the output is a splined shaft that couples directly to the winch drum or the drive sprocket.
Documentation: 20-item exploded view and illustrated parts list, so spares can be ordered by item number.
Applications
Order spares straight from the exploded view: each callout number matches one line in the parts list, which shows an outline and part number for every item. Tell us the callout number and we will confirm the part.
