DRILLING TOOLS · BELLING BITS
Three-wing belling bit, soil
Large three-wing belling bit for soft to stiff silt and clay, and loose to medium-dense sand and gravel. KD1500–KD2000, 3 catalogue sizes.
| Size | DiameterD · mm | DiameterD1 · mm | Bit heightH1 · mm |
|---|---|---|---|
| KD1500 | 1460 | 3000 | 3600 |
| KD1800 | 1760 | 3600 | 3900 |
| KD2000 | 1960 | 4000 | 4200 |
3 catalogue sizes from KD1500 to KD2000. Catalogue values; dimensions in mm. Other sizes on request.
Overview
An open, cage-style body with three toothed wings, built for large bells in soil. The drawing shows body diameter D, the opened diameter D1 and bit height H.
The catalogue lists three large sizes: KD1500 (1460 mm body, 3000 mm D1, 3600 mm high), KD1800 (1760 / 3600 / 3900 mm) and KD2000 (1960 / 4000 / 4200 mm).
Applications
How to order
To order, give us the pile diameter, the bell diameter, the soil profile at the toe and your rig model with its Kelly connection. We reply by email within one business day.
