DRILLING TOOLS · FULL CASING EQUIPMENT
Power pack
Hydraulic power pack for casing oscillators, with an electric motor or a diesel engine.
| Parameter | Electric 60 | Electric 105 | Diesel 180(240) | Diesel 245(325) |
|---|---|---|---|---|
| For oscillator series | BGJ1000–BGJ2000 | BGJ1000–BGJ2000 | BGJ1000–BGJ2000 | BGJ2200–3000 |
| Engine | Three-phase induction motor | Three-phase induction motor | Cummins 6CTA8.3-240 | Cummins 6LTAA8.9-C325 |
| PowerkW | 60 | 105 | 180(240) | 245(325) |
| Speedrpm | 1500 | 1500 | 2200 | 2200 |
| Pump outputL/min | 60 | 90 | 2×200 | 2×208 |
| Operating pressurebar | 300 | 300 | 270 | 270 |
| Hydraulic tank capacityL | 600 | 850 | 1300/400 | 2200/460 |
| Dimensions (L × W × H)mm | 2000×1500×1800 | 2500×1500×2200 | 3500×1700×2000 | 4000×2000×2000 |
| Weightkg | 2700 | 3650 | 5400 | 6500 |
Four configurations — electric 60 and 105, diesel 180 (240) and 245 (325) kW — with the oscillator series each one serves, pressure, tank capacity, dimensions and weight. Catalogue values; dimensions in mm unless stated. Other sizes on request.
Overview
The power pack drives the oscillator's clamping, oscillating and lifting cylinders. Choose an electric motor or a diesel engine to suit the site; custom builds are available on request.
Applications
How to order
To order, give us the oscillator model, electric or diesel drive, and the supply voltage for electric units. We reply by email within one business day.
